(1) Engine torque reserve ﹥30%，To ensure more stable and stronger power ;
(2) The classic synchronizer shift gearbox has an optimized speed range and enhanced durability, providing better efficiency and smoother gear shifting ;
(3) The optimized machine barycenter design assures stable and efficient attcching for mutiple implements ;
(4) The optimized machine barycenter design assures stable and efficient attaching for mutiple implements.
PARAMETRS:
| Item | XT704-4D（驾驶室） |
| Engine Model | 4D32RT30P704 |
| Engine Power（kW） | 51.5 |
| Engine Rated Speed（rpm） | 2400 |
| Air intake system / Fuel System | Turbo Charged |
| Gearbox | Dry double-acting clutch, 12F+12R synchronizer shifting |
| PTO Speed（rpm） | 540/720 |
| PTO Power（kW） | ≥43.7 |
| Traction（kN） | ≥20 |
| Hydraulic outlet valves No. | 2 |
| Max Lifting Capacity（kN） | ≥14 |
| Tillage depth adjustment method | Force adjustment, position adjustment, force position comprehensive adjustment, strong rise and strong fall. |
| Wheelbase（mm） | 2075 |
| Min.Steering Radius（m） | 3.8 |
| 3-Point Hitch Type | Category 2 |
| Fuel Tank Capacity（L） | 100 |
| Front wheel track（mm） | 1373、1473、1583 |
| Rear wheel track（mm） | 1300、1414、1530 |
|
Tyre Specifications |
（Front wheel）8.3-24 R-1/8.3-24 PR-1/9.5-24 R-1/9.5-24 PR-1 （Rear wheel）11-32 R-1/11-32PR-1/14.9-30 R-1/14.9-30 RR-1 |
| Max Front Counterweight（kg） | 208 |
| Max Rear Counterweight（kg） | 164 |
| Min Machine weight（kg） | 2800 |
| Machine Dimensions（L*W*H）（mm） | 4070*1810*2540 |
