描述
| Item | Value |
| Maximum rated lifting capacity | 220t |
| Maximum main boom length | 85m |
| Maximum lifting moment | 1304t.m |
| Maximum single rope speed of winch | 130m/min |
| Maximum slewing speed | 1.3r/min |
| Maximum travel speed | 1.0km/h |
| Counterweight weight (rear) | 79t |
| Maximum counterweight | 79+25t |
| Ground bearing pressure | 0.118Mpa |
| Engine model | weichai WP10 |
| Engine maximum power | 247/2000kw/rpm |
| Engine maximum torque | 1600/1200-1400N.m/rpm |
