| Item |
Value |
| Maximum Lifting Height |
62m |
| Maximum Lifting Moment |
2043kN-m |
| Maximum Lifting Capacity |
50t |
| Maximum Single Rope Speed of Main Hoist |
120m/min |
| Boom Full Extension/Retraction Time |
100/120s |
| Boom Full Raising/Lowering Time |
60/90s |
| Maximum Slewing Speed |
2.0r/min |
| Total Operating Weight |
41800kg |
| Maximum Counterweight |
4.7+5.8t |
| Overall Length |
14260mm |
| Overall Width |
2650mm |
| Overall Height |
3800mm |
| Outrigger Span (Width * Length) |
7.4×6.05m |
| Engine Model |
weichai WP8.320E61 |
| Engine Maximum Power |
235/2100kW/rpm |
| Engine Maximum Output Torque |
1300/1200-1600N-m/rpm |
| Maximum Travel Speed |
85km/h |
| Minimum Turning Radius |
12m |
| Maximum Gradeability |
0.47 |
| Approach Angle |
18° |
| Departure Angle |
12° |
| Minimum Ground Clearance |
250mm |
