| Chassis |
Surface Mount |
| Mounting Type |
Surface Mount |
| Packaging |
Tape & Reel (TR) |
| Published |
2016 |
| Part Status |
Active |
| Moisture Sensitivity Level (MSL) |
1 (Unlimited) |
| Termination |
Solder |
| Maximum Operating Temperature |
80°C |
| Minimum Operating Temperature |
-20°C |
| Application |
WiMax™ |
| Structure |
COMPONENT |
| Frequency |
5.55GHz |
| Polarization |
LINEAR HORIZONTAL/LINEAR VERTICAL |
| Impedance |
50Ohm |
| Gain |
2.6dBi, 0.7dBi |
| Frequency Range |
3.1GHz~8GHz |
| RF/Microwave Device Type |
ANTENNA-OTHER |
| Radio Frequency Series/Standard |
WiFi |
| Antenna Type |
Chip |
| Voltage Standing Wave Ratio (VSWR) |
2.5 |
| Number of Frequency Bands |
1 |
| Frequency Group |
UHF 3GHz~4GHz, SHF f > 4GHz |
| Frequency (Center/Band) |
3.5GHz, 5.6GHz |
| Omnidirectional |
NO |
| Height |
990.6μm |
| Length |
8mm |
| Width |
6mm |
| Reach SVHC |
Unknown |
| Radiation Hardening |
None |
| RoHS Status |
ROHS3 Compliant |
