描述
| Attribute | Reference Value |
|---|---|
| Factory Lead Time | 18 Weeks |
| Chassis | Through Hole |
| Mounting Type | Through Hole |
| Package/Case | Radial, Can – Snap-In |
| Dielectric Material | ALUMINUM (WET) |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -25°C~105°C |
| Packaging | Bulk |
| Series | VXH |
| Published | 2004 |
| Size/Dimension | 0.984Dia 25.00mm |
| Tolerance | ±20% |
| JESD-609 Code | e3 |
| Lead-Free Code | yes |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Number of Terminals | 2 |
| Terminal | Snap in |
| ECCN Code | EAR99 |
| Terminal Finish | Tin (Sn) |
| Application | General Purpose |
| Capacitance | 220μF |
| Voltage – Rated DC | 450V |
| Packaging Method | Box |
| Thread Distance | 10mm |
| Capacitor Type | Aluminum Electrolytic Capacitors |
| Lead Spacing | 0.394 10.00mm |
| Lead Diameter | 2 mm |
| Voltage | 450V |
| Leakage Current | 0.94393mA |
| Ripple Current | 1.17A |
| Polarization | Polar |
| Lifetime (Hours) | 5000 hours |
| Triangle | 0.2 |
| Ripple Current @ Low Frequency | 1.37A @ 120Hz |
| Ripple Current @ High Frequency | 1.918A @ 10kHz |
| Ripple Current (AC) | 1.17A |
| Feature | General Purpose |
| Diameter | 25mm |
| Height | 35mm |
| Seat Height (Max) | 1.457 37.00mm |
| SVHC Compliance | No SVHC |
| Radiation Hardening | No |
| RoHS Status | ROHS3 Compliant |
